Chemical Hose

EPDM Acid and Alkali Resistant Chemical Hose

Our heavy-duty EPDM acid and alkali resistant rubber hose is engineered for safe fluid transfer of corrosive chemicals, dilute acids, and alkaline solutions.

Quick Specifications

Internal Hose	White, smooth, Ultra High Molecular Weight Polyethylene (UHMWPE).
Reinforcement	High-strength synthetic cord and helix wire.
Cover	Smooth/Wrapped finish, EPDM rubber, resistant to chemicals, weathering, and ozone
Application	Soft wall hose designed with ultra-high molecular weight polyethylene tube, excellent in handling a wide range of chemicals, petroleum products, and oil
Temperature	-40°C ~ +120°C
Working Pressure	16 Bar / 240 Psi

Request A Quote WhatsApp

SAE / DIN / EN Standards

100% Proof Tested

OEM Branding Available

MOQ Flexible

Overview

Product Overview

The EPDM Acid and Alkali Resistant Rubber Hose is designed specifically for conveying corrosive chemical media, industrial wastewater, and acidic/alkaline fluids. Engineered to excel in chemical processing, oil refining, paper manufacturing, and foundry applications, this hose offers exceptional resistance to chemical degradation, thermal stress, and environmental aging.

The core consists of a high-purity black EPDM rubber inner layer, capable of handling dilute acid and alkali solutions at concentrations below 40% (at temperatures up to 45°C), dilute sulfuric acid, hydrochloric acid up to 90% concentration at ambient room temperature, and chemical liquids/gases with pH values between 4 and 10. Reinforcement is provided by high-tension textile rope plies or steel wire braiding, ensuring high structural integrity and flexibility under a constant working pressure of 20 Bar (290 PSI).

The heat-resistant blue EPDM outer rubber cover protects the hose body against severe outdoor exposure, ozone cracking (complying with ISO 7326:2006 IDT standards), and weather aging. With a strict 4:1 safety burst factor, this hose ensures continuous operation and maximum safety in industrial chemical environments.

Size	Hose I.D.	Hose O.D.	Working Pressure		Burst Pressure		Weight	Length
inch	mm	mm	Bar	Psi	Bar	Psi	kg/m	M/roll
3/4”	19	32	16	240	48	720	0.76	40
1″	25	38	16	240	48	720	0.94	40
1 1/4”	32	45	16	240	48	720	1.17	40
1 1/2”	38	52	16	240	48	720	1.50	40
1 3/4”	45	59	16	240	48	720	1.73	40
2”	51	64	16	240	48	720	2.02	40
2 1/4”	57	73	16	240	48	720	2.20	40
2 1/2”	64	80	16	240	48	720	2.44	40
3”	76	94	16	240	48	720	3.40	40
4”	102	123	16	240	48	720	5.29	40
6”	152	176	16	240	48	720	10.35	20

Key Features

Premium black EPDM inner tube providing superior resistance to chemical corrosion and pH 4-10 fluids
Reinforced with high-tension textile rope or braided steel wire for 20 Bar working pressure
Capable of transferring dilute acids/alkalis (<40% conc.), H2SO4, and HCl under controlled temperatures
Heat-, weather-, and ozone-resistant blue EPDM outer cover complying with ISO 7326:2006
Strict 4:1 safety burst pressure factor preventing unexpected chemical leaks and line ruptures
Wide size availability from 1/4" to 2" with lightweight weight per meter options
Full customization available for specific inner/outer diameters, pressures, and cover colors

Structure

Hose Structure

Inner Layer: Smooth, black chemical-resistant EPDM rubber compound
Reinforcement: Multi-ply high-tensile textile cord plies or high-strength steel wire braiding
Outer Layer: Smooth blue EPDM rubber resistant to heat, ozone, and outdoor weathering

Applications

Chemical Processing and Industrial Acid/Alkali Delivery Lines
Petroleum Refineries and Petrochemical Plant Operations
Paper Mills, Pulp Processing, and Dyeing Facilities
Metal Plating, Foundry, and Steel Mill Chemical Treatment
Industrial Wastewater Treatment and Neutralization Plants
Agricultural Fertilizer and Dilute Acid Spraying Equipment

Advantages

Why Choose This Product

Superior EPDM formulation drastically extends hose lifespan when conveying aggressive chemical media

Flexible structure with high tension plies maintains smooth fluid flow without kinking

High 4:1 burst safety factor ensures hazardous chemical transfer meets site safety requirements

ISO-certified ozone and heat resistance prevents outer cover cracking under direct sunlight exposure

Available in long continuous lengths up to 120m to reduce pipeline joints and connection leak points

Technical Data

Technical Specifications

Internal Hose	White, smooth, Ultra High Molecular Weight Polyethylene (UHMWPE).
Reinforcement	High-strength synthetic cord and helix wire.
Cover	Smooth/Wrapped finish, EPDM rubber, resistant to chemicals, weathering, and ozone
Application	Soft wall hose designed with ultra-high molecular weight polyethylene tube, excellent in handling a wide range of chemicals, petroleum products, and oil
Temperature	-40°C ~ +120°C
Working Pressure	16 Bar / 240 Psi

FAQ

Frequently Asked Questions

What chemical media can be safely transferred using this EPDM hose?

It is suitable for dilute acid/alkali solutions (<40% conc., ≤45°C), room-temperature dilute H2SO4, HCl, and fluids with pH 4-10 (excluding nitric acid).

What working pressure does this chemical hose support?

The hose supports a maximum working pressure of 20 Bar (2.0 MPa / 290 PSI) with a safety factor of 4:1.

Is the EPDM outer cover resistant to sunlight and outdoor weather?

Yes, the outer blue EPDM rubber compound complies with ISO 7326:2006 standards for ozone and heat resistance.

Can nitric acid be transferred through this hose?

No, nitric acid is an oxidizing acid and is excluded; EPDM is recommended for non-oxidizing dilute acids and alkalis.

Can the hose dimensions and cover color be customized?

Yes, we offer customization for inner/outer diameters, lengths up to 120m, working pressure ratings, and cover colors.

Request a Quote

Get a Quotation for EPDM Acid and Alkali Resistant Chemical Hose

Send us your specifications - size, length, pressure rating, quantity and destination port. Our sales engineer will respond within 4 business hours with a quotation, datasheet and lead time.
